Model NO.AC82-S
Features
◆ Easy to install and use , wireless
◆ Clear and smooth video browsing; intelligent transmission giving full play to capabilities of the network
◆ Online firmware upgrade, and synchronous updating of the functions and experience
◆ Support two ways talk and echo cancellation , noise suppression
◆ Remote real-time monitoring , Support Andorid and IOS smart device
◆  2-megapixel 1920x1080 resolution,clear picture quality
◆ Double light source for night vision  (night vision distance of 7 meters), provide infrared light/white LED supplement light, to achieve night vision color image effect.
◆ With built-in rechargable battery , support long battery life, which normal working up to 8 months and standby for 15 months
◆ 2.4G Wi-Fi supported (IEEE802.11b/g/n)
◆  Cloud storage, Micro SD card (up to 128GB) and mobile phone video recording supported
◆ QR code intelligent connection and network allocation supported
◆ Support Human Detection 、Car recognition 、Intelligent fence 、Pet Recognition 、Package Recognition and Intelligent Push
◆  IP65 Easy installation: support 1 / 4 universal screw bracket and magnetic suction bracket
Specifications
Main  Processor
SOCARM
Image Sensor
Cmos Sensor1/3" Color CMOS Sensor
LensM12,f: 3.3mm,F2.0, 200w
Visual angleH(Horizontal)°; V(Vertical)55°; D(Diagonal)110°
Minimum Illumination0.01Lux
Audio
Input/Output built-in Microphone and speaker
Audio CompressingAAC
Video
Video CompressingH.264/H.265
Lighting Frequency50Hz, 60Hz
Frame Rate15fps
Maximum Resolution1920*1080P
Light Source for Night VisionDouble light source with medium power infrared LED (850nM wavelength) and white LED , irradiation distance :7 meters
Network
Wireless Network2.4G Wi-Fi(IEEE802.11b/g/n), with External antenna
Protocols SupportedTCP/IP、UDP/IP、DHCP、RTMP、MUTP
IP Address SupportedDynamic IP address supported
AI
Intelligent FeaturesSupport Human Detection 、Car recognition 、Intelligent fence 、Pet Recognition 、Package Recognition and Intelligent Push
Alarm
Alarm NotificationAlarm push by mobile APP,white LED flashing and alarm sound warning
Wake up
Wake up MethodPIR body induction wake-up, and remote wake-up
Recording
Recording MethodAlarm triggered recording, and manual recording
Video StorageCloud storage, local Micro SD card, and mobile phone memory
Indicator
LED IndicatorRGB tri-color lamp indicating the status of power/network signal/functionality
Battery
Capacity9000mAH
RemovabilityUnremovable
Battery Life8 months(Record 20 10S videos per day)
Standby15 months
Charge VoltageDV 5V+-5%/1.5A
Charge time17hours
ProtectIP65;over-current/over-discharge/over-charge/short circuit/charging protection at high & low temperatures
Power Consumption
Standby1.68mW(4V 0.42mA)
Day1W(3.8V 264mA)
Night2.23W(3.8V 588mA)
Interface
PowerMicro USB
SD Card1 Micro SD card (up to 128GB supported)
Keyone reset key  and one power key
Installation
method1/4 universal screw holes
Environment
Dustproof and waterproofIP65
Operating Environment-10° ~ 45°C  /10% ~ 80%  (no condensation)
Storage Environment-20°C ~ 60°  /0% ~ 90% (no condensation)
Prodoct dimension
dimension(LxWxH)81.3*119.2*80.6(mm)
The bare weight500g
finished weight600g
MaterialABS+PC
ColorWhite
Certification
CertificationCE,FCC,RoHS,WEEE,MSDS,UN38.3
