PRODUCTS

AC86
  • Specification
  • Drawing
  • Download
  • Feedback
Model NO.AC86
Features
◆ Easy to install and use
◆ Clear and smooth video browsing; intelligent transmission giving full play to capabilities of the network
◆ Online firmware upgrade, and synchronous updating of the functions and experience
◆ Two-way voice intercom supported; echo eliminated; noise suppressed
◆ Compatible with Android; remote real-time monitoring supported with the IOS intelligent terminal
◆  2-megapixel high resolution (1920X1080) for clear picture quality
◆ Lighting for infrared night vision (with a night vision distance of 7m); 24h around-the-clock monitoring; IR-CUT switching; free of color cast in the daytime; clearer night vision
◆  Intelligent push to filter out useless information
◆ 2.4G Wi-Fi supported (IEEE802.11b/g/n)
◆ Intelligent storage algorithm, small space can accommodate more content, support Micro SD card, cloud storage
◆ QR code intelligent connection and network allocation supported
◆  Supporting human contour detection, activity zone,  intelligent push and pet snapshot
◆Small and exquisite appearance, various colors
Specifications
Main  Processor
SOCARM
Image Sensor
Sensor1/3" color CMOS sensor
LensM12, f: 3.6mm, F2.0, 2-megapixel
Visual angleH (horizontal) 85 degrees; V (vertical) 48 degrees; D (diagonal) 100 degrees
Minimum illumination0.01Lux
Audio
Input/OutputTwo-way voice intercom available (built-in Microphone and speaker)
Audio compression methodAAC
Video
Video compression methodH.264/H.265
Lighting frequency50Hz, 60Hz
Image frame rate15fps
Maximum Image Resolution1920*1080P
Light Source for Night VisionIRCUT double filter automatic switching, 6 infrared lamps (850nm wavelength), irradiation distance:5 meters
Network
Wireless Network2.4G Wi-Fi (IEEE802.11b/g/n), built-in antenna
Protocols SupportedTCP/IP, UDP/IP, DHCP, RTMP, MUTP
IP Address SupportedDynamic IP address supported
AI
Intelligent functionIntelligent push, pet snapshot, human contour detection, package detection,motion tracking
Alarm
Alarm detectionMotion Detection
Alarm linkageSupport video recording, sound alarm
Alarm notificationAlarm push by mobile APP
PTZ
PTZ rotation angleH (horizontal) 0° ~ 355°; V (vertical) -20° ~ 90°
Interface
Power Supply1 Micro USB interface, DC 5V/1A
SD card1 Micro SD card (up to 128GB)
Keys1 function key
Other
Adjustable lensNot adjustable
LED indicationMonochrome white light (power/network signal/function indicator)
Video storage methodMicro SD card (up to 128GB) local storage, cloud storage
Install methodCeiling or wall hanging
Environment
Dustproof and waterproofno
Operating environment-10° ~ 45°C /10% ~ 80% (no condensation)
Storage environment-20°C ~ 60° /0% ~ 90% (no condensation)
 Color
Appearance colorWhite
Specification
Dimensions (L*W*H)75mm*75mm*110mm
Net Weight of Bare MachineApprox. 190g
Certification
CertificateCE, FCC, RoHS
