AHD KHF 1.3MP
  • Specification
  • Drawing
  • Download
  • Feedback
Model NO.KHFHTC130S
Video Output ModeAHD/CVI/TVI/CVBS
Camera
Image SensorIMX225
DSPHTC960E
Image Resolution960P / 960H
Effective Pixels1280*960
TV SystemPAL/NTSC
Electronic Shutter1/25s~1/50,000s , 1/30s~1/60,000s
S/N Ratio≥50dB
Scanning SystemProgressive Scan
Lens
Focus Length3.7mm
Focus ControlFixed
Lens TypeFixed
Pixels2M Pixels
Motor Iris SupportNO
Camera Features
Day/Night  NO
OSD Menu Language YES
White Balance AUTO / MANUAL
Gain Control AUTO
Noise Reduction DNR
WDR NO
OSD Support YES
UTC YES
General
HousingMetal
BracketYES
Dual VoltageNO
IR Cut FilterNO
HeaterNO
Operation Temperature-10℃ ~ +60℃ RH95% Max
Storage Temperature-20℃ ~ +60℃ RH95% Max
Power SourceDC12V±10%, 150mA
Dimension30(W) x 19(H) x 30(D)mm
Weight150g
