AHD LDA 8MP AF
  • Specification
  • Drawing
  • Download
  • Feedback
Model NO.KLDAHTC8005XESLKLDAHTC8004XES
Video Output ModeAHD: 8M@15fps, 5M@20fps/12.5fps,
4M/2M@30fps/25fps;
CVI: 8M@15fps/12.5fps, 4M/2M@30fps/25fps
TVI: 8M@15fps/12.5fps, 5M@20fps/12.5fps,
4M/2M@30fps/25fps;
AHD/TVI/CVI: 8M@15fps/12.5fps,
4M/2M@30fps/25fps
Camera
Image Sensor1/2.8" SONY Starvis Back-illuminated CMOS sensor1/2.8'' SONY CMOS sensor
Image Resolution8M:3840*2160 5M:2592*1944
4M:2560*1440 2M:1920*1080
8M:3840*2160 4M:2560*1440 2M:1920*1080
TV SystemPAL/NTSCPAL/NTSC
Electronic ShutterAutoAuto
Minimun Illumination0.01Lux0.01Lux
Scanning SystemProgressive  ScanProgressive  Scan
Lens
Focus Length2.7-13.5mm Motor Zoom2.7-13.5mm Motor Zoom
Focus ControlAutoAuto
Lens TypeAutoAuto
Night Vision
IR Cut FilterYESYES
Infrared LED 42µ x 4PCS 42µ x 4PCS
Infrared Distance30M30M
IR StatusAGC Auto ControlAGC Auto Control
Camera Features
Starlight//
Day/Night  YESYES
OSD Menu YESYES
WDR YESYES
UTC YESYES
Noise Reduction 3DNR3DNR
White Balance AUTO / MANUALAUTO / MANUAL
Gain Control AUTOAUTO
General
HousingIP67IP67
BracketNONO
Operation Temperature-10℃ ~ +60℃ RH95% Max-10℃ ~ +60℃ RH95% Max
Storage Temperature-20℃ ~ +60℃ RH95% Max-20℃ ~ +60℃ RH95% Max
Power SourceDC12V±10%,750mADC12V±10%,750mA
Dimensionφ159 x 132(H)mmφ159 x 132(H)mm
Weight1.6Kgs1.6Kgs
