| Model NO. | KHSP2HTC200FE | KHSP2HTC200F | KHSP2HTC200ESL | KHSP2HTC200ESP |
| Video Output Mode | AHD/TVI/CVI: 2M@30fps/25fps | AHD/TVI/CVI: 2M@30fps/25fps | AHD/TVI/CVI: 2M@30fps/25fps | AHD/TVI/CVI: 2M@30fps/25fps |
| Camera | ||||
| Image Sensor | 1/3" CMOS Sensor | 1/2.9" CMOS Sensor | 1/2.8" SONY Starvis Back- | 1/2.8" SONY Starvis Back- |
| Image Resolution | 2M:1920*1080 | 2M:1920*1080 | 2M:1920*1080 | 2M:1920*1080 |
| TV System | PAL/NTSC | PAL/NTSC | PAL/NTSC | PAL/NTSC |
| Electronic Shutter | Auto | Auto | Auto | Auto |
| Scanning System | Progressive Scan | Progressive Scan | Progressive Scan | Progressive Scan |
| Lens | ||||
| Focus Length | 3.7mm Taper Pinhole Lens | 3.7mm Taper Pinhole Lens | 3.7mm Taper Pinhole Lens | 3.7mm Taper Pinhole Lens |
| Focus Control | Fixed | Fixed | Fixed | Fixed |
| Lens Type | Fixed | Fixed | Fixed | Fixed |
| Night Vision | ||||
| IR Cut Filter | YES | YES | YES | YES |
| Infrared LED | NO | NO | NO | NO |
| Infrared Distance | NO | NO | NO | NO |
| IR Status | AGC Auto Control | AGC Auto Control | AGC Auto Control | AGC Auto Control |
| Camera Features | ||||
| Starlight | / | / | YES | Super Starlight |
| Day/Night | YES | YES | YES | YES |
| OSD Menu Language | YES | YES | YES | YES |
| WDR | DWDR | DWDR | YES | YES |
| UTC | YES | YES | YES | YES |
| White Balance | AUTO / MANUAL | AUTO / MANUAL | AUTO / MANUAL | AUTO / MANUAL |
| Noise Reduction | DNR | 3DNR | 3DNR | 3DNR |
| Gain Control | AUTO | AUTO | AUTO | AUTO |
| General | ||||
| Housing | Plastic | Plastic | Plastic | Plastic |
| Bracket | NO | NO | NO | NO |
| Operation Temperature | -10℃ ~ +60℃ RH95% Max | -10℃ ~ +60℃ RH95% Max | -10℃ ~ +60℃ RH95% Max | -10℃ ~ +60℃ RH95% Max |
| Storage Temperature | -20℃ ~ +60℃ RH95% Max | -20℃ ~ +60℃ RH95% Max | -20℃ ~ +60℃ RH95% Max | -20℃ ~ +60℃ RH95% Max |
| Power Source | DC12V±10%,150mA | DC12V±10%,150mA | DC12V±10%,150mA | DC12V±10%,150mA |
| Dimension | 70(W) x 40(H) x 119(D)mm | 70(W) x 40(H) x 119(D)mm | 70(W) x 40(H) x 119(D)mm | 70(W) x 40(H) x 119(D)mm |
| Weight | 350g | 350g | 350g | 350g |
