| Model NO. | CLQ1-W22 |
| Camera | |
| Sensor Type | 1/3" CMOS |
| Shutter | Adaptive Shutter |
| Fixed Lens | 3.6mm@F1.6, Diagonal Field of View: 91°, Horizontal: 77°, Vertical: 41° |
| Pan & Tilt Lens | 3.6mm@F1.6, Diagonal Field of View: 91°, Horizontal: 77°, Vertical: 41° |
| Pan/Tilt Rotation Angles | Horizontal 0°-355°, Vertical 0°-90° |
| Lens Interface Type | M12 |
| Day/Night Mode | ICR Infrared Filter |
| Digital Noise Reduction | 3D Digital Noise Reduction |
| Interfaces/Buttons | |
| Wide Dynamic Range | / |
| Storage Interface | Micro SD Card (up to 512GB) |
| Power Interface | 1 |
| Reset Button | 1 |
| Compression Standards | |
| Power Switch | H.265/H.264 |
| Video Compression Standards | Adaptive Bitrate |
| Sensor Type | Adaptive Bitrate |
| Video | |
| Maximum Video Size | Maximum 1920x1080, supports dual stream |
| Frame Rate | Maximum 15fps |
| Image Flip | Support |
| Backlight Compensation | Support |
| Software Features | |
| Working Mode | Smart Mode/Constant Power Mode/AOV Mode/Power-Saving Mode/Sleep Mode |
| Smart Alarm | Person/Vehicle Detection |
| Sound and Light Alarm | Support sound alarm and light alarm |
| Two-Way Audio | Support |
| Auto Tracking | Support |
| Gun-ball Linkage | / |
| Pan/Tilt Presets | Support, up to 6 presets |
| Wi-Fi | |
| Wi-Fi Standard | IEEE 802.11a/b/g/n/ac/ax,WiFi 6,Support 2.4G/5G dual-band |
| Bluetooth | Bluetooth v5.4 |
| Solar Panel | |
| Output Power | 8W |
| Standard Output Voltage | 5V |
| Maximum Output Current | 1.52A |
| Operating Temperature | -20~60℃ |
| Dimensions | 264×172mm |
| Lithium Battery | |
| Battery Capacity | 8800mAh |
| General Specifications | |
| Operating Temperature and Humidity | -10℃~55℃, Humidity less than 95% (non-condensing) |
| Power Supply | Type-C Charging Port DC 5V/2A (user needs to provide) |
| Infrared Illumination Distance | 20m |
| White Light Irradiation Distance | 20m |
| Dimensions (mm) | 154×117×168mm |
| Weight | 790g (bare unit) |
