| Model NO. | S02TH |
| System |
| Main Processor | MX3520 |
| Operating System | Embedded LINUX |
| RAM | DDR3 512MB |
| ROM | EMMC 8GB |
| Screen |
| Dimensions | 7 inch IPS HD LCD screen |
| Resolution | 600*1024 |
| Camera |
| Type | 2MP camera |
| Sensor | 1/5" GC2145 |
| Resolution | NIR 800*600 15fps |
| Lens | 2.4mm |
| Camera |
| Type | Daily camera |
| Sensor | 1/2.8" SONY Starvis Back-illuminated CMOS sensor IMX307 |
| Resolution | Color 1920*1080 30fps |
| Lens | 4.5mm |
| Body temperature detection |
| Measuring site | Wrist surface |
| Temperature range | 35℃-42℃ |
| Temperature measuring distance | Away from the wrist 1-3cm |
| Temperature measurement accuracy | ± 0.3℃ |
| Measuring Environment | 5℃-40℃，Indoor and windless environment |
| Face recognition |
| Detection Type | Support face recognition, face comparison, mask detection, living body detection, mask recognition |
| Face recognition distance | Within 1.2m |
| Face database capacity | Max support 30,000 faces |
| Face Posture | Horizontal less than 35°, vertical less than 50° |
| Occlusion | Ordinary glasses and short fringe have no effect on recognition. |
| Expression | Under normal circumstances, slight expressions do not affect recognition. |
| Response Speed | About 200ms |
| Face exposure | Support |
| Local Storage | Support storage of 25,000 records |
| Recognition area | Full screen recognition |
| Upload Method | TCP, HTTP, MQTT |
| Network Functions |
| Network protocol | IPv4, TCP/IP, HTTP, MQTT |
| Interface protocol | Private protocol |
| Security Mode | Authorized password |
| Event linkage | Voice broadcast，Abnormal event upload to the platform, Alarm output |
| System Upgrade | Support remote upgrade |
| Accessories |
| Supplementary light | IR light, LED white light |
| Identification Module | / |
| Audio out | Built in Speaker support voice broadcast after successful recognition |
| Network Module | / |
| Interface |
| Network Interface | RJ45 10M/100M Network Adaptation |
| Alarm Input | / |
| Alarm Output | Support external alarm, linkage abnormal alarm, DC 30V 1A |
| Relay Output | Support, NO, NC, COM |
| RS485 interface | Support |
| Wiegand interface | Support external Wiegand protocol equipment |
| TF card slot | / |
| HDMI | / |
| Reset key | Support |
| Anti-disassembly switch | / |
| General |
| Housing | Aluminum alloy, Ultra-white tempered glass panel, IP66 |
| Operating Temperature | 5℃-40℃，Indoor and windless environment |
| Working humidity | 10% -90% Non-condensing |
| Storage Temperature | -40 ° C ~ 70 ° C |
| Storage humidity | 5% -95% Non-condensing |
| Protection Level | / |
| Power Supply | DC12V |
| Power dissipation (maximum) | ≤ 12 W |
| Dimensions (mm) | 219 (W) * 140 (H) * 21.5 (T) |
| Bracket size (mm) | φ27*189 |
| Product weight (without packaging) | 1050g |
| Product weight (including packaging) | 2050g |
| Packing size (mm) | 405*183*156 |
| Installation Method | Desktop installation/Floor installation/Gate machine installation/Column installation/Wall installation |
